TriCaster TC1 - VIZRTEAN  3770012031473

TriCaster TC1 (2RU)
NewTek TriCaster TC1 is the most complete production system on the planet for the modern producer, publisher, and content creator. Equipped with industry-leading, software-driven live production technology and hundreds of advanced production capabilities for existing and emerging video workflows, including native IP processing, switching, streaming, recording, and delivery in HD, 3G, and 4K Ultra HD, integrated video playback, recording, and replay, Skype TX software integration, dual-channel live streaming, real-time social media publishing, and more, TriCaster TC1 provides everything you need to create incredible content, embrace new ideas, technologies, and platforms, and reach viewers whenever and wherever they watch.


Video Input: Up to 16x simultaneous external video inputs, supporting any combination of compatible sources in resolutions up to 4K UHD at frame rates up to 60fps (2160p 59.94)
Network Video Input: 16x IP video inputs via NDI®, resolution-independent, with support for key and fill
SDI Video Input: 4x 3G/HD/SD-SDI connections supporting video input in any combination of standard formats, resolutions, and frame rates
PTZ: Support for up to 16 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422 and IP, with integrated controls and preset system
Skype TX: Native support for up to 2 simultaneous Skype® video call inputs via Skype TX software integration
Video Output: Configurable for up to 4 independent video mix outputs, with simultaneous delivery via IP and SDI
Network Video Output: IP video output via NDI, optionally configurable for:
4x independent video mix outputs
1x 4K UHD video mix output
SDI Video Output: 4x 3G/HD/SD-SDI connections, optionally configurable for:
4x independent 3G/HD/SD video mix outputs
1x 4K UHD video mix output via 3G-SDI quad-link grouping
Stream Output: 2x resolution-independent streaming video outputs, independently configurable, with simultaneous stream archive
Multiviewer Output3 x multiviewer outputs supporting standard display resolutions
1 x DVI user interface with multiviewer
1 x HDMI multiviewer
1 x DisplayPort multiviewer

2RU chassis with 400W PSU and multi-tiered hardware and software fail-safe
19.0 x 3.5 x 19.57 in (48.3 x 8.9 x 49.7 cm) with rack ears attached
